Fluid Inclusion and Ore Microscopy-Petrography Laboratory


Person in charge: Assoc.Prof.Dr. Tolga OYMAN
Phone: +90 232 3017334

Fluid Inclusion (microthermometric) studies are an essential and valuable component of the dataset gathered for research/exploration on ore deposits. These studies mainly focus on heating/freezing experiments conducted on ore and rock forming minerals collected from the target area. The obtained data is mainly used to understand the nature and evolution of the ore forming fluids and genesis of the studied deposit.

General view of the fluid inclusion and ore microscopy-petrography laboratory.



To achieve this, a Linkam THMSG600 heating/freezing stage mounted on a Leica DM LP microscope (up to 50x magnification) is installed in the Fluid Inclusion and Ore Microscopy-Petrography Laboratory. The THMSG600 is one of the most widely used heating and freezing microscope stages.  The THMS600 is used in many applications where high heating/freezing rates and 0.1°C accuracy and stability are needed. This stage is suitable for heating work up to 600°C, and freezing work down to -196°C.  The stage is controlled by a TMS94 programmable controller. Digital images of fluid inclusions are captured by a PixeLink PL-A662 digital camera.



Linkam THMSG 600 heating/freezing stage (-180/+600°C) mounted on a Leica DM LP microscope (up to 50x magnification), TMS94 programmable controller and a liquid nitrogen cooling system.



Doubly polished sections for fluid inclusion studies are prepared by Struers RotoPol-35/PdM-Force-20 grinding/polishing machine.  RotoPol-35 is suitable to work with 300 mm diameter grinding/polishing discs. With variable speeds from 40 to 600 rpm, it is possible to carry out grinding, lapping and polishing processes on a variety of geological samples.

RotoPol-35/PdM-Force-20 grinding/ polishing machine for preparation of doubled polished thin sections.

Fluid Inclusion and Ore Microscopy-Petrography Laboratory also includes two reflected-transmitted polarizing light microscopes for petrographic studies on ore and rock samples. Both Leica DM2500P (with Leica DFC290 digital camera) and Nikon E400POL (with Nikon coolpix 995 digital camera) microscopes are being used for thin and polished section determinations. Polished samples for ore mineralogy /petrography are prepared by Struers TegraPol-15 grinding/ polishing machine with variable speeds (40-600 rpm in steps of 10 rpm) and with a disc of 200 mm diameter.

Leica DM2500P with Leica DFC290 digital camera (left) and Nikon E400POL with coolpix995 digital camera microscopes (right).



TegraPol-15 grinding/ polishing machine for preparation of polished sections (ore and rock samples mounted on epoxy resin).



Laboratuvarda bulunan makina ve techizat listesi:
Struers TegraForce-1 modülü destekli Tegrapol-15 parlatma makinası
Struers Rotopol-35 parlatma makinası
Struers Epovac vakumlama makinası
Vommak mikrometrik kesme cihazı
Nikon Eclipse 6400POL polarizan ve üstten aydınlatmalı mikroskop (dijital kamera destekli)
Leica DM2500P polarizan ve üstten aydınlatmalı mikroskop (dijital kamera destekli)
Leica DMLP polarizan mikroskop (dijital kamera destekli)-Isıtma/Soğutma Tablası monte edilmiştir.
Linkam THMS600 model ısıtma-soğutma tablası (-196°C ile +600°C aralığında)
Linkam TMS94 ısı kontrol cihazı ve Likit Nitrojen Pompası
